A timber frame and 71 mm-deep sashes accommodate a 40–48 mm triple-glazed unit with two Low-E coatings and argon-filled cavities. The result is a whole window U-value of 1.1 W/m²K, with the cord, weight and pulley operation of a traditional sash.
Full frame, glazing and tested weather-tightness data for your architect, energy consultant or builder.
| Product guidance – as standard | |
| Frame | 100 x 192 mm (lining width x frame depth). Mortise and tenon joints, glued and mechanically fixed |
| Sash | 39 x 71 mm top rail and stiles, 90 x 71 mm bottom rail, 45 x 71 mm meeting rail |
| Mullion / transom | 39 x 71 mm top rail and stiles, 90 x 71 mm bottom rail, 45 x 71 mm meeting rail |
| Sill projection | 35 mm, 50 mm, 60 mm, 70 mm |
| Staff / parting beads | Timber |
| Wood moisture content | 12–19% |
| Glazing beads | Internally beaded with external rebate up-stand giving the appearance of putty glazing |
| Air permeability | 600 Pa (Class 3) – EN 1026 / EN 12207 |
| Water tightness | 200 Pa (Class 5A) – EN 1027 / EN 12208 |
| Wind resistance | 1600 Pa (Class 4) – EN 12210 |
| Whole window U-value | 1.1 W/m²K to EN ISO 10077-1 |
| Whole window acoustic rating | 29 dB (-2;-4) with 4/16/4/16/4; 30 dB (-1;-2) with 6/14/4/14/8.8 (44.2 laminated acoustic) – BS EN ISO 10140-2:2021 |
| Anticipated life expectancy | 60 years with regular maintenance |
| Product Specification | |
| Material | Frame and sash in engineered redwood, bottom cill in solid hardwood (standard). Engineered hardwood, Accoya or European oak optional |
| Finish | Three-coat spray-applied factory finish using water-based microporous paint/stain (Teknos Aqua prime 1410, Aqua mid 2901, Aqua top 2600) |
| Colour | White – RAL 9016 (standard). Any RAL from RAL Classic range. Stain from Zyle Fenster stain range |
| Glazing | Triple glazed, 4/14/4/14/4 Low-E top sash – 4 tgh/14/4/14/4 tgh bottom sash (standard). Ug-value 0.6 W/m²K; g-value 0.52–0.55 |
| Glass standard | Factory-fitted 40–46 mm sealed triple-glazing unit tested to BS EN 1279. Composition (from outside): 4 mm float Low-E – 16 mm argon – 4 mm float – 16 mm argon – 4 mm float Low-E |
| Perimeter spacer bars | White warm edge perimeter spacer with white warm edge integral spacers (standard). Silver and black optional |
| Glazing bars | Applied bars to both faces of sealed unit, fixed with double-sided glazing tape and capped with clear silicone |
| Trickle ventilation | Concealed through frame head trickle ventilator. EA 1700, 4400, 5000 mm² |
| Child restrictor | Angel lock (standard). Traditional Sash Stop optional. Optional 100 mm opening restrictor |
| Operation | Cord, weight and pulley system concealed within the frame |
| Timber species | Engineered laminated pine, hardwood or Accoya. FSC or PEFC certified |
| Moisture content | 12% +/- 2% on delivery |
| Ironmongery | Lockable Fitch fastener and two finger pulls to bottom sash. Options in colour and finish |
| Cill | Hardwood. Projections 35–110 mm |
| Horns | Solid feature horns to top sashes included as standard |
| Fixing | Installation per Zyle Fenster recommendations and best building practice |
| Warranty | 10-year manufacturing and material defects; 10-year opaque finishes; 6-year stain finishes; 10-year sealed unit seals; 2-year ironmongery |
Download the Triple Glazed Sash brochure, datasheets and CAD details for your project.
The Triple Glazed Sash keeps the cord, weight and pulley operation of a heritage window while accommodating a glazing unit deep enough to deliver Passivhaus-aligned thermal performance.
It is the right answer where the look of the home calls for a sash, but the way you want to live in it calls for modern fabric performance.
Frames and sashes are made in engineered redwood, hardwood, Accoya or European oak, with a solid hardwood cill as standard.
A factory-applied Teknos three-coat finish is available in any RAL or wood stain, with concealed trickle ventilation, child restrictors and a full ironmongery range to complete the window.
Honest answers to the questions self-builders and homeowners ask when specifying triple glazed timber sash windows for a new or upgraded home.
Contact UsFor new builds and well-insulated homes, yes. Triple glazing reduces heat loss, removes cold spots near the window and lowers heating bills throughout the year.
A whole window U-value of 1.1 W/m²K is typical, with a centre-pane Ug of 0.6 W/m²K. In practice, this means warmer rooms, no condensation and far less perceived draught near the glass.
Yes. The Triple Glazed Sash is suitable for Passivhaus and low-energy homes. We will review your project targets and confirm the right glazing make-up to support certification.
Yes. Sashes are slightly deeper to accommodate the triple-glazed unit, but front-face profiles, sash horns and applied glazing bars maintain the traditional appearance on the elevation.
Yes. Laminated acoustic panes can be specified within the triple-glazed unit, achieving 30 dB or higher, particularly useful for homes on busy roads or in urban locations.
