Aluminium Windows

Reynaers Ultra
Slim SL38

These slimline aluminium windows come in a choice of three external profiles to complement the architecture of any modern building.

West Waterford, Ireland

Product overview

Contact us Download PDF

The Reynaers SlimLine 38 windows are highly insulated, and with a thermal break, the water and air tightness tests give superb results, plus an impressive acoustic performance of 45 dBRw. Double or triple glazing is offered, with a choice of four glass types. The frames can be anodised or finished in a choice of RAL colours.

Contact us Download PDF

Specifications

Product guidance

Double glazing

1.4 W/m²K (Uw value depending on the frame/ vent combination and glass unit specification).

Triple glazing

1.1 W/m²K (Uw value depending on the frame/ vent combination and glass unit specification).

Inward and outward opening casement windows.

Glazing method

Drained and ventilated glazing with EPDM synthetic rubber gaskets.

Choose from a full range of polyester powder coat colours and anodised finishes.

Finishing

Choose from a full range of polyester powder coat colours and anodised finishes.

Dual colour

Dual colour available offering a different colour inside and out.

Profile assembly

Weather stripped profiles with polyamide thermal breaks.

BRE Rating

Corresponds to the BRE Global Green Guide online generic specification for windows and achieves a summary rating of A, Element Number 1231500007.

Security

Meets the very stringent requirements to be awarded the Secured By Design accreditation.

Air permeability

Up to 600 Pa (class 4).

Wind load resistance

Up to 1600 Pa (class C4).

Water tightness

Up to 600Pa (class 9A).

Acoustic performance

Rw (C;Ctr) = 37 (-1;-4) dB/ 44 (-2;-5) dB, depending on the glazing type.

Product guidance - as standard

Min. Visible width frame-vent

67mm

Min. Visible width frame-vent

80mm

Min. Visible width T-profile

48mm

Max. height vent

2200mm

Max. width vent

1600mm

Max. weight vent (element)

170 kg

Overall system depth frame

99mm

Overall system depth vent

86mm

Rebate height

13.5mm

Min. Glass thickness vent

16mm

Max. Glass thickness vent

55mm
