Schuco Passivhaus Certified AWS 90.SI

Q: Is the Schüco AWS 90.SI certified to Passivhaus standard?

Yes. The Schüco AWS 90.SI is certified by the Passivhaus Institute, meeting the stringent requirements for Passivhaus thermal performance with a basic frame depth of 95mm.

Q: What makes the AWS 90.SI suitable for low-energy buildings?

Its combination of a 95mm frame depth, advanced polyamide thermal break technology, and compatibility with triple glazing allows the AWS 90.SI to achieve the outstanding thermal insulation values required for low-energy and Passivhaus-certified buildings.

Q: What sustainable materials are used in the AWS 90.SI?

The AWS 90.SI Green Generation incorporates renewable raw materials – including castor oil in polyamide insulating bars – alongside sustainably sourced foam and gasket materials, reducing fossil fuel dependency without compromising performance.

Q: What colour options are available for the Schüco AWS 90.SI?

The system is available in a full range of polyester powder coat colour options and anodised finishes, including dual colour configurations for a different finish inside and out – supporting a wide variety of architectural styles.

Q: Can the AWS 90.SI be used in both residential and commercial projects?

Yes. The Schüco AWS 90.SI is a versatile, high quality aluminium window system suitable for design-led residential projects, self-build homes, and commercial buildings requiring Passivhaus or high-insulation performance.

The Schüco AWS 90.SI is a Passivhaus-certified aluminium window system built for design-led, sustainable architecture where outstanding thermal insulation and the individual character of a building must both be achieved. With narrow profile face widths, concealed vents, and the capacity to accommodate single and double-vent block window designs, it meets the highest demands of modern low-energy construction while remaining a genuinely refined architectural product.

Get in Touch

Features
Specifications
Downloads

Passivhaus Certification Meets Architectural Design Freedom

The Schüco AWS 90.SI is the ideal choice for projects where the highest thermal insulation requirements must be met without sacrificing design quality. With a basic frame depth of 95mm, Passivhaus standard is achievable, and the AWS 90 BS.SI+ series now extends this capability to double-vent block window designs. The system also incorporates renewable raw materials into its insulating bars, foam, and gaskets – including castor oil as an ecological alternative to fossil fuels – positioning it as a high quality, genuinely sustainable aluminium window system for the most demanding projects.

Passivhaus Institute-certified thermal performance

Narrow profile face widths with concealed vent design

Renewable raw materials in insulating bars and gaskets

Single and double-vent block window configurations

Schüco AWS 90.SI Technical Specifications

Key technical information for the Schüco AWS 90.SI Passivhaus-certified aluminium window system, including depth, glazing, and performance data.

Specification	Detail
Basic frame depth	95 mm
Passivhaus certification	Certified by the Passivhaus Institute
Vent configurations	Single and double-vent block window designs
Insulating bar material	Polyamide with renewable raw materials including castor oil
Triple glazing	Supported – required for Passivhaus performance thresholds
Finishing	Full range of polyester powder coat colours and anodised finishes; dual colour available
Sustainability	Significant use of renewable raw materials in insulating bars, foam, and gaskets

Schüco AWS 90.SI Product Downloads

Download technical datasheets, system brochures, and Passivhaus certification documents for the Schüco AWS 90.SI aluminium window system.

Downloads

PDF 2 files

Schuco Passivhaus AWS90.SI Window AWS Fenstersysteme Optimised

CAD 1 file

Schuco Passivhaus AWS90.SI+ window

Outstanding Thermal Insulation Without Visual Compromise

The Schüco AWS 90.SI is designed to achieve optimum thermal insulation at the system level, meeting the highest thermal insulation requirements for Passivhaus certification with a basic frame depth of 95mm. Narrow profile face widths and concealed vents allow the realisation of harmonious block window solutions – preserving the clean lines and architectural style of the building while delivering the thermal performance that low-energy construction demands.

Triple glazing is central to the performance of the AWS 90.SI, contributing directly to the outstanding thermal insulation values required for Passivhaus standard. The result is a window system that provides genuine energy efficiency and reliable protection against heat loss, across all weather conditions, throughout its service life.

Sustainable by Design – Built for the Future

The Schüco AWS 90.SI Green Generation introduces a meaningful step forward in sustainable aluminium window manufacturing. Renewable raw materials – including castor oil as an ecological substitute for fossil fuels – are incorporated into polyamide insulating bars, foam, and gaskets for the first time, reducing reliance on fossil-derived materials without affecting the highest standards of performance.

This commitment to sustainability sits alongside a full range of colour options via polyester powder coating and anodised finishes, including dual colour configurations. Whether specified for contemporary commercial buildings, high-specification new-builds, or architect-designed private homes, the AWS 90.SI offers aesthetic appeal and technical depth in equal measure – a window system genuinely built to meet the highest demands of modern, sustainable architecture.

Get a Quote

View our Gallery

Schuco Passivhaus AWSSL double glazing window

Frequently Asked Questions

Technical and specification questions answered for architects, Passivhaus consultants, and specifiers considering the Schüco AWS 90.SI aluminium window system.

Is the Schüco AWS 90.SI certified to Passivhaus standard?

What makes the AWS 90.SI suitable for low-energy buildings?

What sustainable materials are used in the AWS 90.SI?

What colour options are available for the Schüco AWS 90.SI?

Can the AWS 90.SI be used in both residential and commercial projects?
